TNThomas
Well-known member
Well I finally got a trailer as its about 2" wider than my truck bed, so it will come soon
Attachments
-
Three wheel mini-bike thing.
- Thread starter TNThomas
- Start date
TNThomas
Well-known member
Ok, I am ditching the mount and triple tree design that came on the trike. I used some big left over steel DOM tubing from my dube buggy spindles to make the frame to triple tree mount. The original one was a little off center/tilted anyways. Triple tree to fork mounts are the original mounting brackets that came from the bumper that is on my dune buggy. The bumper was from an 80s Toyota 4-runner. Should be pretty stout! Ill try and have it all welded together by the end of the night. 8 plan on making a small racks to go on the front as well.
Attachments
-
20251204_103419.jpg -
20251204_111134.jpg -
20251204_111227.jpg -
Master Hack
Well-known member
That thing is purdy cool, but that exhaust looks dagerous! Almost as dangerous as that triple clamp!
TNThomas
Well-known member
Ok, forks are fixed. Ill probably cut off the pokey parts. But I may leave a little metal on there for an offset headlight or two. We shall see.
Attachments
-
20251206_154904.jpg -
20251206_154936.jpg -
Whitetrashrocker
Inmate #952016
I want to see you sitting on it.
Those bars look low.
Those bars look low.
TNThomas
Well-known member
The bars are just dangling right now, I need to adjust some tension on the brake/trottle/electrical lines before I bolt them up.
TNThomas
Well-known member
This thing is so much easier to work on than the buggy! Cleaning up angles, lines, cables, and a bunch of little things. Im going to adjust the seat angle, adjust the exhaust tubing, and I'll work on the rack this week.
Do you folks know which model of drive and drive clutch this is? Series 40?
Do you folks know which model of drive and drive clutch this is? Series 40?
Whitetrashrocker
Inmate #952016
Looks like a 30.
40s are symmetrical belt.
40s are symmetrical belt.
Master Hack
Well-known member
Where is the belt police? Officer Denny! Please issue a citation to this belt offender!
You know the penalty for using a non approved belt? Thats right! Its changing belts in the cold PNW rain, in a mud hole, with a pair of vice grips and cresent wrench.
Do yerself a favor! Change now!
You know the penalty for using a non approved belt? Thats right! Its changing belts in the cold PNW rain, in a mud hole, with a pair of vice grips and cresent wrench.
Do yerself a favor! Change now!
Last edited:
Whitetrashrocker
Inmate #952016
But but but that's a premium drive belt.
panchothedog
Well-known member
- Messages
- 2,788
- Reaction score
- 3,730
That is a 30 series torque converter, not a 40.
Denny
Canned Monster
He’s heard my warnings before. He knows the penalty of using cheap belts.
ezcome-ezgo
G'me sumthin to write on
ezcome-ezgo
G'me sumthin to write on
Actually here is a better version everyone can use in the future.
TNThomas
Well-known member
The "Changing belts in the cold PNW rain, in a mud hole, couldn't be further from the truth!"
TNThomas
Well-known member
Got the rack going.
Attachments
-
TNThomas
Well-known member
Doing the diamond plate like the buggy. Recessed and supported from the bottom.
Last year I acquired a ton of old school manual sheet metal working tools from a much older gentleman that I use to shoot competitively with. He was nationally ranked in Free Pistol during the 90s, and his father was a glider pilot during the invasion of Normandy. Kind guy with a big character. I suspect he knew he was on his last days and didn't want these going to the scrap yard after he passed. He was a career Tig welder and machinist for a big name aerospace company. These are all tools that were pulled out of dumpsters after the company switched to more "modern" tools. He passed away last month. I feel that he would approve of my use of them.
-Diacro tube bender (Weighs about 400lbs)
-Diacro 24" sheet metal sheers
-Pexto sheet metal bender
-Thor Turrent hole punch, with 10 dies
-Beverly shear (second biggest model)
-Whitney Jenson corner notcher
-Diacro 90 degree notcher
-Roper Whitney Angle Iron Shear
-90 degree angle iron shear.
-1 copy of "Karting" by Tex Smith
My goal is to get all this stuff mounted. Pretty fun getting work done without power tools.
Last year I acquired a ton of old school manual sheet metal working tools from a much older gentleman that I use to shoot competitively with. He was nationally ranked in Free Pistol during the 90s, and his father was a glider pilot during the invasion of Normandy. Kind guy with a big character. I suspect he knew he was on his last days and didn't want these going to the scrap yard after he passed. He was a career Tig welder and machinist for a big name aerospace company. These are all tools that were pulled out of dumpsters after the company switched to more "modern" tools. He passed away last month. I feel that he would approve of my use of them.
-Diacro tube bender (Weighs about 400lbs)
-Diacro 24" sheet metal sheers
-Pexto sheet metal bender
-Thor Turrent hole punch, with 10 dies
-Beverly shear (second biggest model)
-Whitney Jenson corner notcher
-Diacro 90 degree notcher
-Roper Whitney Angle Iron Shear
-90 degree angle iron shear.
-1 copy of "Karting" by Tex Smith
My goal is to get all this stuff mounted. Pretty fun getting work done without power tools.
Attachments
-
TNThomas
Well-known member
Last edited:
Denny
Canned Monster
You are one lucky man! I don’t know if you know the value of those tools but you have been given a great, great gift. The Beverly shear goes for around $1,000 the last time I priced them. You can buy new blades for them and they still make them. Read up on sharpening the blades for the shears and such. Be careful they will remove a finger in the blink of an eye.
