Carter Brothers Manuals & Documentation

[Hellion]

Can't have too many manuals/parts lists. These are listed at EC Carburetors but will supplement the listing at BMI Karts.

Carter Bros Manuals & Documentation

Carter Brothers Karts​

Carter is proud to partner with SYM of Hsinchu, Taiwan to distribute a complete line of ATV's and scooters from 50cc to 600cc. The Carter/SYM partnership will provide Carter dealers with one of the most diverse and highest quality lineup of products available in the power sports industry. Read on to find out more about the long history of Carter Brothers Mfg. Co., Inc.

Carter Brothers Mfg. Co., Inc. officially opened its doors in the spring of 1936 in the small southeast community of Brundidge, Alabama. Under the leadership of the brothers W.W. Carter and Charlie Carter, the company prospered in the manufacturing of agricultural equipment, lawnmowers, and personal gardening equipment. During those first years, the Carter brothers committed to one simple philosophy, to make the highest quality products at the best possible price.

During the late 1960's Carter Brothers produced the first go-kart for its growing dealer network. After W.W. Carter became sole owner of Carter Brothers Mfg. Co., Inc. in June of 1971, his innovations in go-kart making propelled his once small company into the industry leader it is today.

On April 28th, 1997, Mr. Carter received the designation of Small Business Person of the Year for the state of Alabama, awarded by the United States Small Business Administration. This distinction is awarded to only one person in each state on an annual basis. Mr. Carter celebrated with his wife Dessie, family members, and other designees during a week of recognition in Washington D.C. hosted by the Small Business Administration.

Throughout the years, Carter Brothers has grown from a small manufacturing firm to a 235,000 square foot facility which houses management, sales, engineering, research and development, quality control, manufacturing, assembly, and warehousing. Today Carter Brothers uses the most technologically advanced machinery in our industry. Laser technology, robotic welding, powder coating finishes, and computer assisted designs are all a part of today's manufacturing process. Throughout this transformation, Carter Brothers has continued to focus its efforts on producing the same high quality products envisioned by its founders more than 70 years ago.

No matter how much Carter Brothers grows in the future, its same time honored traditions and values will be preserved. We will continue to create innovative products for valued customers and for the dealers who have become a vital part of our family.



[Hellion]

All of these were sold by Northern Tool + Equipment at one time and are still on their website...

​

​

Carter Brothers Double Seat Go-Kart — 6.5 HP, Model# 2906TR-3018​

Double seats, two head rests, foam-padded frame, full suspension and more make this go-kart the one you want for off-road action! U.S.A.
Features + Benefits

• 6.5 HP Tecumseh pull-start engine
• Full suspension
• 2 seat adjustable - seat to pedal adjustable 34in to 40in.
• Two head rests
• Dual 3-point safety belt system
• Live axle (two wheel drive)
• Torque drive converter
• All-time halogen running lights
• 18in. rear tread tires
• 15in. front tread tires
• Blue frame
• Dual continuously adjusting band brakes
• Overall dimensions of 86in.L x 53in.W x 63in.H
• For gently to uneven terrain with moderate hills
• Approximate top speed of 25 MPH
• Ground clearance is 5in. from front axle an d8in. from rear axle
• Warranties: 2 year limited engine warranty provided by engine manufacturer; 90 day frame warranty; 30 day warranty against defects in materials or workmanship on clutch, bearings, and sprocket
• Warranty excludes items subject to normal wear and tear and abuse

Carter Brothers Camo Trailhunter Go-Kart — 10 HP Item# 131257​

Product Summary​

Take on the roughest terrain with this 10 HP Go-Kart featuring full suspension and large knobby, “Snow-Hog” tread tires! Torque converter drive system, recoil start, dual halogen running lights and slide adjust dual bench/AdvantageÆ seat cushion. Front tires: 16 x 650-8; rear tires: 18 x 950-8. Truck ship. U.S.A. Factory shipped.​

Features + Benefits

• 10 HP Tecumseh OHV recoil engine with remote choke
• Torque converter
• Dual headrests
• Enclosed live axle (two wheel drive)
• Pull start
• Cammo green
• All-time safety lights
• Utility rack
• 16in. knobby front tires
• 18in. knobby rear tires
• 2 seat adjustable - seat to pedal distance adjusable 34in. to 40in.
• Dual continuously adjusting band brakes
• Approximate top speed of 35 MPH
• Overall dimensions of 86in.L x 53in.W x 63in.H
• Dry weight approximately 443 lb.
• For gentle to uneven terrain with moderate hills
• Warranties: 2 year limited engine warranty provided by engine manufacturer; 90 day frame warranty; 30 day warranty against defects in materials or workmanship on clutch, bearings, and sprocket
• Warranty excludes items subject to normal wear and tear and abuse
• Truck ship

Carter Brothers 6.5 HP Double Seat Go-Kart, Model# 2606-KX​

Product Summary​

Stitched double seat cushion plus 3-point seat belt for great comfort. Red frame has nose cone and Nerf padded side bars. 15/6.00 x 6in. rear tires; 13/5.00 x 6in. front. Belt clutch and stub axle. KartWheels decal. Overall size: 67 1/2in. L x 40in. W x 52in. H. Truck Ship. U.S.A.
Features + Benefits

• 6.5 HP Tecumseh Engine O/V, 4 cycle
• Room for two in double seat
• Lights for safer action after sunset!
• Padded brush guards!
• Seat belts included

Carter Brothers Double Seat Go-Kart — 6.5 HP, Model# 2636KLA-3415​

Features + Benefits​

• 6.5 HP Tecumseh recoil engine
• 2 seat adjustable seat to pedal ddistance 29.5in. to 34.5in.
• 3-point safety belt system
• Live axle (2 wheel drive)
• Belt clutch/pulley
• Transfer drive shaft
• All-time running lights
• 15in. rear knobby trail tires
• 13in. front knobby trail tires
• Blue frame with side nerf cars and front brush guard
• Continuously adjusting band brake
• Groud clearance of 5in. from front axle and 7in. from rear axle
• Approximate top speed of 20 MPH
• Overall dimensions of 69in.L x 44in.W x 53inH
• Dry weight approximately 235 lbs.
• For gentle terrain and mild hills
• Warranties: 2 year limited engine warranty provided by engine manufacturer; 90 day frame warranty; 30 day warranty against defects in materials or workmanship on clutch, bearings, and sprocket
• Warranty excludes items subject to normal wear and tear and abuse

​

Carter Brothers Talon Go-Kart — 150cc, 2-Seat, Blue, Model# GX 150 2R​

Product Summary​

Tackle some hills with this powerful 150cc electric start kart that can reach speeds up to 38 MPH. Full suspension handles uneven terrain smoothly.

Features + Benefits

• 150cc, 4-stroke engine (12.5 HP @ 7500 RPM)
• Full suspension go-kart
• Electric start
• 19in knobby tires
• 2 seat - adjustable with 37in to 41in. seat to pedal distance
• Automatic transmission with reverse gear
• 4-wheel hydraulic disc brakes
• Utility rack
• Dual headlights
• Rack and pinion steering
• Swing-arm rear suspension
• 4-point seat belts
• All wheel fenders
• Parking brake with brake light
• Metalflake blue
• Reaches speeds of approximately 38 MPH
• For sloping to uneven terrain with moderate hills
• Overall dimensions of 86in.L x 56in.W x 52in.H
• Dry weight approximately 463 lb

​

Carter Brothers Double Seat Go-Kart — 11 HP, Model# 2911TR-4015​

​

Product Summary​

Take a friend along on this adult size, power-packed 11 HP Go-Kart! Electric Start engine, dual seats, double head rests, foam-padded frame, 3-point safety belts and more make it a safe and fun ride! U.S.A.

Features + Benefits

• Full suspension
• two seats - adjustable seat to pedal distance 30in to 40in.
• Two head rests
• Dual 3-point safety belt system
• Live axle (2 wheel drive)
• Torque converter drive
• All time halogen running lights
• Please see the 'Help' section for Product Warranty Details
